HP-250D/B/C-PS Peel And Seal Pocket Envelope Making Machine
Product Overview
Peel And Seal Pocket Envelope Making Machine is used for producing big size pocket envelope (open end envelope) with peel and seal function inline.
It includes air-suction paper feeding system, folding system, gluing system, peel and seal function system, counting system and delivery system. With the developing for more than 10 years, this model machine is stable producing and easy setting.
Key features
It includes air-suction paper feeding system, folding system, gluing system, peel and seal function system, counting system and delivery system. With the developing for more than 10 years, this model machine is stable producing and easy setting.
Technical Specifications
Model | | HP-250D-PS | | HP-250B-PS | | HP-250C-PS
Paper weight | | 60-157 gram | | 60-157 gram | | 70-157 gram
Size range of envelope | | Min.65x70mm | | Min.100x110mm | | Min.120x150mm
Max.180x300mm | | Max.260x400mm | | Max.360x520mm
Size range of sticker | | Min.10x120mm | | Min.10x120mm | | Min.10x120mm
Max.40x300mm | | Max.40x360mm | | Max.40x360mm
Capacity | | 9000 pieces/hour | | 12000 pieces/hour | | 8000 pieces/hour
Total power | | 4.75 kw | | 5.0 kw | | 5.75 kw
Machine weight | | 2000 kg | | 2500 kg | | 3000 kg
Machine size | | 3000x1000x1200mm | | 3300x1200x1500mm | | 3500x1400x1800mm
