HAOXING PRODUCT
TJ-392/A Self Seal Envelope Making Machine
Product Overview
Envelope Gumming Machine is used for applying an adhesive strip on the flap (dextrin).
It includes air suction paper feeding system, gluing system, drying system, delivery system. With the developing for more than 10 years, this model machine is stable producing and easy setting.
Key features
It includes air suction paper feeding system, gluing system, drying system, delivery system. With the developing for more than 10 years, this model machine is stable producing and easy setting.
Technical Specifications
Model | | TJ-392 | | TJ-392A
Capacity | | 6000-22000 pieces/hour | | 6000-15000 pieces/hour
Size ranges blank envelopes | | Min.100x100mm Max.390x490mm | | Min.100x100mm Max.500x660mm
Paper gsm | | 60-200gsm | | 60 – 200gsm
Size ranges of gummed | | Min.5x100mm Max.30x280mm | | Min.5x100mm Max.30x320mm
Power | | 8.0kw | | 10.0kw
Machine Weight | | 1200kg | | 1500kg
Machine Size | | 4500x1100x1150mm | | 5000×1250×1150mm
